GoodData Plugins #4: Polar Area Chart

Written by Patrik Braborec  |

Share
GoodData Plugins #4: Polar Area Chart

GoodData Dashboard Plugins allow developers to customize GoodData Dashboards according to their individual needs or business goals. If you want to develop your own plugin, check the tutorial.

Note: Missed the third article in this series covering our Insight Groups plugin? Read it here. Also, check the next article from the dashboard plugins series, which focuses on Radial Bar Chart.

This article describes the Polar Area Chart plugin, which displays multivariate data in the form of a two-dimensional chart. It uses a circular graph with multiple axes rising from the center, each representing a different variable. The data is plotted using lines that connect data points on each axis, forming a closed shape that resembles a spider's web. This visualization method allows for easy comparison of multiple variables and their relationships within a dataset.

Example of the Polar Area Chart plugin
Example of the Polar Area Chart plugin

Create Your Polar Area Chart Plugin

If you want to create your own Polar Area Chart plugin, below are the steps to do it.

Step 1: Clone dashboard-plugin-examples repository

git clone https://github.com/gooddata/gooddata-dashboard-plugins.git

Step 2: Navigate to polar_area_chart_plugin

cd polar_area_chart_plugin

Step 3: Set environment variables

Make sure you have your .env and .env.secrets files with the correct values. After you clone the repository, you will see a .env.secrets.template file in the polar_area_chart_plugin folder. You will need to remove “template” from the filename to set up everything correctly.

For .env, you will need to define four variables:

# GoodData backend (code name)
BACKEND_TYPE=tiger

# GoodData host
BACKEND_URL=

# GoodData workspace id
WORKSPACE=

# GoodData dashboard id
DASHBOARD_ID=

If you open a GoodData dashboard, you can find the BACKEND_URL, WORKSPACE_ID, and the  DASHBOARD_ID in the URL like this:

https://<BACKEND_URL>/dashboards/#/workspace/<WORKSPACE_ID>/dashboard/<DASHBOARD_ID>

For .env.secrets, you will need only one variable:

# GoodData API token
TIGER_API_TOKEN=

Check the Create an API token documentation for more information.

Step 4: Check dependencies

Make sure that the dependencies in the package.json file are aligned with the version of the SDK dashboard component you use in your project (if you are embedding the dashboards with the GoodData SDK).

{
  ...
  "@gooddata/sdk-ui-dashboard": "^9.2.0" <-- must match in the plugin and your project
  ...
}

Step 5: Build a production version

Build a production version of the plugin using the command npm run build-plugin, or yarn build-plugin. If you have already built this plugin, first delete the dist folder.

Step 6: Upload the built plugin

Upload the built plugin to your hosting. GoodData does not provide hosting for your plugin builds. When you build your plugin, you have to host it yourself in a publicly available location supporting HTTPS.

Also, make sure the hosting of your plugin is included in the allowed plugin hosts by CSP Policy (documentation).

Step 7: Create plugin metadata object

Create a plugin metadata object using the npm run add-plugin or yarn add-plugin command. For more information, run the npm run add-plugin –help or yarn add-plugin --help command.

Copy the plugin object-id noted in the console output for the next step.

Step 8: Link the plugin to the dashboard

Run the npm run link-plugin,or yarn link-plugincommand. Once you link the plugin to the dashboard, it becomes visible, and you can start using it!

Give It a Try

If you want to try dashboard plugins, check out our free trial. If you would like to discuss dashboard plugins or whatever you have on your mind, reach out to us on our community Slack.
